The ZRBY series silver micro powder has the characteristics of good dispersibility, non agglomeration, and good compatibility with glass powder. It is mainly used as the main filler for sintered conductor pastes such as back electrode silver paste and ceramic metallization paste in photovoltaic cells.
+86-18988684013Powder growth mechanism, component segregation, particle size and distribution, microstructure control, aggregation, surface state and purity control methods, etc.
High temperature reaction process, process thermodynamics, and kinetic laws.
Multi component combination relationship, homogeneous mixing, crushing, dispersibility, surface additive combination, stability and adaptability control.
Process energy efficiency management and lean production management.
| Model | ZRBY-01 | ZRBY-02 |
| Application Areas | Photovoltaic cell back electrode silver paste, ceramic metallization paste and other sintering conductor pastes | |
| Average particle size (μm) | 0.45-0.80 | 0.40-0.75 |
| Bulk density (g/cm³ ) | 1.30-2.50 | 1.30-2.50 |
| Tap density (g/cm³ ) | 3.50-5.00 | 3.50-4.80 |
| Specific surface area （m²/g） | 0.90-1.90 | 1.20-2.00 |
|
Electron microscope image |
|
|
