MLCC, also known as multi-layer ceramic capacitors, is a key component widely used in electronic devices, and its performance directly affects the overall performance of electronic products. The conductivity, stability, and compatibility with other materials of conductive copper paste, as the main material for the internal electrodes of MLCC, directly affect the performance and reliability of MLCC.
+86-18988684013Control of characteristics such as particle size, morphology, specific surface area, and surface modification of metal/ceramic powders.
Control of physical and chemical properties, sintering performance, etc. of inorganic additives (glass, microcrystalline glass).
Control of rheological properties, viscosity, dispersibility, and mesh passing characteristics of organic carriers.
Matching with substrate, upper and lower functional layers (Ohmic contact, co firing, electronic energy level matching, etc.).
Batch supply applicable window width, product batch stability, high reliability.
| Model | Solids(%) |
Viscosity(Pa.S) |
Sintering temperature(℃) |
Media Type | Application size |
| TJ75 | 80.5±1.0 | 26.0～32.0 | 855±10 | X7R、C0G | 0402-1812 |
| TJ63 | 79.8±1.0 | 25.0～31.0 | 930±10 | Y5V、X7R | 0402-1812 |
| TDR81-02 | 73.0±2.0 | 40±10 | 780±10 | X7R | 0805、0603 |
| (Note: The viscosity detection conditions are Brookfield HBDV - Ⅱ+, CP52, 25 ± 0.5 ℃, 10rpm) | |||||
