Gray black paste like fluid, mainly composed of nickel powder, organic resin, and organic solvent, does not contain harmful substances such as lead, separator, chromium, etc., meets Rohs environmental requirements, and is widely used in basic components of chip capacitors.
+86-18988684013Control of characteristics such as particle size, morphology, specific surface area, and surface modification of metal/ceramic powders.
Control of physical and chemical properties, sintering performance, etc. of inorganic additives (glass, microcrystalline glass).
Control of rheological properties, viscosity, dispersibility, and mesh passing characteristics of organic carriers.
Matching with substrate, upper and lower functional layers (Ohmic contact, co firing, electronic energy level matching, etc.).
Batch supply applicable window width, product batch stability, high reliability.
| Model |
Nickel powder particle size(nm) |
Solids(%) |
Viscosity(Pa.S) | Sintering temperature(℃) | Media Type |
| NJ0080 | 300 | 55.0±1.0 | 8～12 | 1250±150 | X7R、X5R |
| NJ9020 | 600 | 56.0±1.0 | 9～11 | 1250±150 | X7R、X5R |
| NJ0050 | 400 | 51.5±1.0 | 9～14 | 1200±150 | C0G |
| (Note: The viscosity detection conditions are Brookfield HBDV - Ⅱ+, CP52, 25 ± 0.5 ℃, 10rpm) | |||||
